Hella Adjustable Control Time Delay Relay, Delay On Release, 12V

Switching power: 420W - Weight (approx. ): 40g Pin lay-out; 30: Positive 12V feed power (from battery for example) 85: Negative / Ground 86: Positive 12V trigger to activate relay and timer (from headlight switch for example) 87: 10 second delayed output positive (Normally open) (to HID ballast for example) 87a: Normally closed and unused (12V positive when 12V on pin 86, power switched to pin 87 after 10S). Here is the answer, a time delay relay. This relay fits most common single or dual beam HID wiring harnesses for an easy fix to prevent HID from starting before cranking the engine. Relays are contact rated at 30A @ 14 VDC, and sealed for waterproof operation 10 second delay before switching On
